Efficient where it counts, aggressive where it matters.

The Revolver LT C3 is the lightest and most capable full-suspension frame Norco has ever built. At the core of its efficiency is our advanced approach to the Flex-Pivot design, letting us get improved performance out of the lightweight inline shocks we’re spec'ing that would typically be reserved for heavier and larger volume air shocks. With modern, aggressive XC geometry, consistant weight distribution across sizes, and a carbon frame layup optimized per frame size for stiffness and compliance, it’s a strong foundation for driving up and charging down.

DETAILS

• Precision and control for all-day efficiency

• All the suspension performance without the weight.

• Customized suspension development to support Revolver's best attributes.

• A lightweight frame that encourages putting the hammer down.

• Balanced weight distribution for top-of-class ride feel across sizes.

• Ride Aligned™ - Perfect fit, dialed handling and personalized setup in minutes.

• No Other Way Limited Lifetime Warranty.

Specs.

Frameset

Frame; Carbon Frame, 120mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™
Fork; RockShox Reba RL, Motion Control, 130mm, 44mm offset,
Rear Shock; RockShox SID LUX Select +, 190x45mm, Std eyelet
Drivetrain

Rear Shifter; Shimano Deore SL-M6200-IR, 12sp
Rear Derailleur    Shimano Deore RD-M6200, SGS, 12sp
Crankset;Shimano Deore FC-MT520, 32T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5)
Bottom Bracket    Shimano BB-MT501, BSA 73mm
Cassette; Shimano Deore CS-M6200-12, 10-51T, 12sp
Chain; Shimano Deore CN-M6100, 12sp
Brakes

Front Brake; Shimano BR-MT420, Resin pads
Front Brake Rotor; Shimano SM-RT54, 180mm, C-lock
Rear Brake; Shimano BR-MT420, Resin pads
Rear Brake Rotor; Shimano SM-RT54, 180mm, C-lock
Brake Levers; Shimano BL-MT401
Components

Handlebar; Norco 6061, 760mm (S1,S2,S3) 780mm (S4,S5), 20mm Rise
Stem; 6061 Alloy, 40mm Length, 35mm Clamp
Seatpost; TranzX YSI36 RAD+, 31.6mm, 150mm (S1, S2) -170mm (S3) -200mm (S4) - 230mm (S5)
Headset    FSA Integrated Sealed Bearings No. 42 ; Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 )
Saddle; WTB Silverado Medium
Grips; Norco Lock On, 130 length
Seatpost Clamp    Norco Alloy Nutted Clamp, 34.9mm ID
Wheels

Front Hub; Shimano HB-TC500-15-B,15x110mm Boost, 32H, C-lock
Rear Hub; Shimano FH-TC500-MS-B, 12x148mm Boost, Micro Spline, 32H, C-lock
Rims; WTB ST TCS 2.0, 27mm ID, 32H
Front Tire; Maxxis NEW Dissector, 3C MaxxTerra EXO, 29X2.4"
Rear Tire; Maxxis NEW Forekaster, 3C MaxxTerra EXO, 29x2.4"
